High Speed Tagless Printing Machine
High Speed Tagless Printing MachineApplication:high rapid garment neck label screen printer in textile knitting industry,the speed can be up to 1500pcs/hr, it is suitable for printing garment tagless, sock or label, rotary wortable,very convenient to load or unload products,lots of customers like it......
Send Inquiry
Product Description
High Speed Tagless Printing Machine
Application:
high rapid garment neck label screen printer in textile knitting industry,the speed can be up to 1500pcs/hr, it is suitable for printing garment tagless, sock or label, rotary wortable,very convenient to load or unload products,lots of customers like it very much because of high quality and low price.
Function:
1. PLC control, human-computer interface, easy operation ;
2. Dried by infrared ray, suitable for general ink ;
3. Eight stations driven by step motor to insure stable and smooth running ;
4. Angle and height of squeegee and flood blade can be adjusted to insure consistent printing pressure
5. Adopts 8 stations rotary worktable, 3pcs for taking in and taking out, 2pcs for printing, 3pcs for drying
6. Eight stations working at the same time with high speed ;
7. Print mode: Automatic | semi-automatic | pedal ;
Technical parameter:
Application:
high rapid garment neck label screen printer in textile knitting industry,the speed can be up to 1500pcs/hr, it is suitable for printing garment tagless, sock or label, rotary wortable,very convenient to load or unload products,lots of customers like it very much because of high quality and low price.
Function:
1. PLC control, human-computer interface, easy operation ;
2. Dried by infrared ray, suitable for general ink ;
3. Eight stations driven by step motor to insure stable and smooth running ;
4. Angle and height of squeegee and flood blade can be adjusted to insure consistent printing pressure
5. Adopts 8 stations rotary worktable, 3pcs for taking in and taking out, 2pcs for printing, 3pcs for drying
6. Eight stations working at the same time with high speed ;
7. Print mode: Automatic | semi-automatic | pedal ;
Technical parameter:
| Max printing area | 130*100mm |
| Max printing speed | 1500pcs/hr |
| Frame size | 360*250mm |
| Rated voltage | AC 110/220V 50/60HZ |
| Rated current | 30A |
| Air consumption | 6bar |
| Dimension | 1350*1300*1550mm |
| Weight | 200kg |
